Rutronik is aiming at 3-phase industrial control cabinets with a DIN-rail mount mains filter series from Schurter. “The housing, with a width of just 44mm, requires extremely little space on the mounting rail,” said distributor Rutronik. “The single-stage filter is available as a standard version or with high attenuation. FPAC RAIL impresses above all with its leakage current of just ...

BLM15VM is an automotive ferrite beads inductor intended to block frequencies around 5.9GHz. Announced by Murata, it is particularly intended for 5G vehicle-to-everything (5G-V2X) applications. “In recent years, the use of high-frequency wireless communication in the automotive sector has increased.,” according to the company. “It is primarily used for content distribution for navigation, audio and other infotainment systems. Improving sensitivity ...

Did you ever dream of surface-mounting wire-wound power resistors? If you do, Vishay has turned that into reality with a series of pick-and-place-friendly cemented wire-wounds. They are actually the company’s existing 3W AC03-CS series of fuseable resistors, with the legs bent into what the company is calling its WSZ lead-form (see photo), available from 1Ω to 100Ω ±5%, with ±200ppm/°C ...

Rhopoint Components is stocking precision current sensing resistors from VPG Foil Resistors. The 1W surface-mount RBF series measures 6.3 x 3.2mm and offers resistances between 0.01Ω and 1Ω. Tolerances down to 0.5% are available between 0.1 and 1Ω, or down to 1% from 10mΩ to 100mΩ. All the series are available with a temperature coefficient of ±25ppm/°C between -25 and ...

Danfoss Power Solutions has launched a 250kVA 560Vac three-phase mains filter for heavy all-electric vehicles that are powered directly from the grid. “All components are rated for 300Arms. EC-LCL1200B-350 [is] a heavy-duty LCL electric filter specifically designed for off-highway applications,” according to the company. “Applications include drilling equipment, material handling equipment and tethered excavators.” It is suited to both 50 ...

TDK has shrunk its 500V gate drive transformers to 11 x 13mm and 11mm high, smaller than its existing E10EM series. The new parts, called the EP9 series and aimed at both IGBTs and mosfets, are built on a MnZn ferrite core with surface-mount L-pin construction. Creepage and clearance is 5mm, peak withstanding is 2.5kVac 50Hz, and coupling capacitance is ...

Vishay has introduced 1, 2 and 3kV multi-layer ceramic capacitors for commercial applications. In seven case sizes from 1206 to 2225, they are made with either C0G (NP0) or X7R dielectric. C0G types are rated at 2kVdc or 3kVdc and come in values between 1.5pF and 82nF, with a temperature coefficient of 0±30ppm/°C from -55 to +125°C. X7R types are ...

Supercapacitors are essential in energy harvesting, processing, and storage systems across various applications. As technology advances, supercapacitors are increasingly used in renewable energy, IoT devices, and more. Eaton Electronics, a leading supplier, offers a wide range of supercapacitors, from miniature components to larger modules for commercial vehicles. These components are crafted using both traditional and innovative technologies, providing versatile solutions ...

TDK has created inductors for automotive power-over-coax applications up to 1.6A. The three parts are an expansion of the 4.5 x 3.2 x 3.2mm ADL4532VK series, and are rated for use across -55 to +155°C. Power-over-coax requires data to be separated from power, and that filtering is what these inductors are intended for. The “series delivers high impedance across a ...

TDK has introduced Class-X2 EMI suppression capacitors that are 20% smaller and more humidity resistant than its previous offerings. Called B3292x, the series meets Grade III Test B for temperature, humidity and bias, and range from 18 x 5 x 10.5mm to 42 x 14 x 25mm  as values increase from 0.1 to 4.7µF. “To meet Grade III Test B, ...
