Nexperia has launched a 1,200V 30mΩ silicon carbide mosfet in a top-side-cooled plastic package with a 18.5 x 14mm footprint. The leaded package is 3.5mm thick is a SOT8107-2, according to the company, which has branded it ‘X.PAK’. The keads have a 1.27mm pitch. “This package, with its compact form factor, combines the assembly benefits of SMD with the cooling efficiency ...

Nexperia has introduced four 40V bi-directional GaN power transistors. With 5V gate drive, maximum on-resistance values of 1.2, 4.8, 8 or 12mΩ are available – see table below – and operation is up to 125°C. Packaging is VQFN16, WLCSP22, WLCSP16 or WLCSP12. They “support overvoltage protection, load switching and battery management systems in mobile devices and laptop computers”, according to ...

Nexperia is claiming a first for an ESD protection diodes compliant to Open Alliance requirements for 10BASE-T1S automotive Ethernet – a member of the ‘single-pair Ethernet’ family. “The exceptionally low capacitance – 0.4pF – of these diodes means they can also be used to protect higher speed applications deploying 100BASE-T1 or 1000BASE-T1 in-vehicle networks while still maintaining signal integrity,” according ...

Nexperia has brought out a portfolio of logic ICs in tiny automotive-qualified MicroPak XSON5 leadless packaging. MicroPak XSON5 is a thermally enhanced plastic enclosure with a 75% smaller PCB footprint than traditional leaded mini logic packages, that also features side-wettable flanks to support automated optical inspection (AOI) of solder joints. Leadless packaging with side-wettable flanks improves manufacturing reliability by allowing ...

Nexperia has introduced a 110V 4A half-bridge gate driver IC. “NGD4300 has been designed for use with dc-dc converters in consumer devices, servers and telecommunications equipment as well as for micro-inverters used in various industrial applications,” according to the company, which is also producing an automotive-qualified version: NGD4300-Q100 for power steering, for example. 4A is the peak sourcing current, and ...

Nexperia has put more single and dual small-signal mosfets into DFN1110D-3 (SOT8015) and DFN1412-6 (SOT1268) packages, with side-wettable flanks for automated optical inspection. “The 1.1 x 1mm DFN1110D-3 package has seen increasingly wide adoption, and is quickly becoming the de-facto industry standard package for small-signal mosfets and bipolar transistors intended for use in automotive applications,” according to the company. “Superior ...

There is some hogwash out there, masquerading as engineering white papers, which are really just click bait to get your contact details. And there are some gems available for the same price. And, in my opinion, ‘BJT. Bipolar junction transistor application handbook‘ from Nexperia is one of the gems. The price is handing over your name, company name and email ...

Nexperia has put an ideal diode, including its p-channel mosfet, and reverse polarity protection, in a 2.1 x 1.25 x 0.95mm TSSOP6 package. Called NID5100, it is aimed at industrial and consumer applications, and has an automotive-qualified cousin named NID5100-Q100. “NID5100 supports ‘OR-ing’ multiple power supplies while retaining reverse polarity protection and provides fast response time for smooth power transfer,” ...

Nexperia has introduced 80 and 100V mosfets in 5 x 6 and 8 x 8mm footprint LFPAK packaging with Rds(on) ranging from 1.8 to 15mΩ, or 2.07mΩ upwards for the 100V parts. “Many mosfet manufacturers focus on achieving high efficiency through low Qg(total) and low Qgd, when benchmarking the switching performance of their devices against alternative offerings,” said the company. ...

Nexperia has created a pair of 17mΩ 13.5A resettable electronic fuses for 12V hot-swap applications in 3 x 3 x 0.75mm DFN3030-10 (SOT8037-1) packaging. NPS3102A and NPS3102B operate with 9 to 18V on the input (21V abs. max) and can limit output current to anywhere between 2 and 13.5A range, programmed using a resistor – the voltage across which can ...
