Diamond Technologies has introduced a series of 28 x 38mm embedded computing modules based around NXP’s i.MX 8M processors, which combine Arm Cortex-A53 and Cortex-M cores. Initial boards are: DTI 8M Plus Quad with NXP i.MX 8M Plus up to four 1.8GHz Cortex-A53 800MHz Cortex-M7 Neural processing unit 1GHz GC7000UL 3D graphics GC520L 2D graphics 1080p60 video decode 1080p60 video ...
Acromag has followed IO intensive profile for its latest 3U VPX single-board computer, built around Intel’s 11th generation Tiger Lake-H Xeon W-11000E processor, and including an XMC mezzanine site. Called VPX7600, its octa-core processor supports up to 32Gbyte dual-channel soldered-down DDR4 ECC memory with data rates of up to 3.2Gtransfer/s. An Intel Gen12 UHD Xe 32EU graphics engine can clock up ...
Aaeon has released two single board computers based on Intel’s Twin Lake Core 3 Processor N355. Called Up Squared TWL and Up Squared Pro TWL, they are also available with Processor N250 or Processor N150 CPUs. The non-Pro measures 85.6 x 90mm and includes two RS-232/422/485 pin wafers, three USB ports, and a 40-pin HAT connector offering GPIO, SPI, I2C, ...
PocketBeagle 2 has quietly been given a quad core upgrade. Initially built around Texas Instrument’s AM6232 IC, which has dual 64bit 1GHz Arm Cortex-A53 CPUs, the development board has been upgraded to TI’s AM6254, which has four of the same cores running at 1.4GHz, plus a 3D GPU that it did not have at the original launch. The change happened ...
Abaco Systems has introduced a SOSA-aligned Open VPX 3U video graphics and GPGPU card. Powered by an Ada Lovelace architecture Nvidia RTX 5000 GPU, with 16Gbyte of GDDR6 ECC memory, GRA117S is designed to support AI and deep learning. 9,728 Cuda cores, 76 RT cores, and 304 Tensor cores are implemented, and there is support for AV1, H.265 and H.264 ...
Aaeon has released its first development kit for Nvidia’s Jetson Orin NX AI system-on-module. Boxer-8654AI-kit is a carrier board equipped with either an 8Gbyte or 16Gbyte Jetson Orin NX module – respectively these have a hex-core or octa-core Arm 64bit Cortex-A78AE (ARMv8.2) CPU. Its IO includes six USB 3.2 Gen 2 ports, an OOB (out-of-band) management box header, and four ...
Frore Systems has chosen Nvidia’s Jetson Orin Nano Super single-board computer as the latest platform on which to demonstrate its novel ‘solid-state’ cooling ‘fans’. This version of the mems-based air shifter, PAK 5C-25, measures 100 x 65 x 9.8mm and can remove up to 25W of heat, according to Frore, meeting the needs of the 67Top/s (INT8) Orin Nano Super ...
For embedded processing Raspberry Pi has revealed the 55 x 40mm ‘Compute Module’ form of Raspberry Pi 5. Processing come from a Broadcom BCM2712 with four 2.4GHz Cortex-A76 cores. All connections to Compute Modules are via two high in count connectors – there are no ‘standard’ interface connectors. There are multiple ram and flash options, and an optional wireless module ...
Raspberry Pi has announced the Wi-Fi and Bluetooth version of its 21 x 51mm Pico 2 microcontroller board. Called ‘Pico 2 W’, it shares the dual 150MHz Arm Cortex-M33 cores, which can be replaced at boot by dual Hazard3 RISC-V processors. Memory remains 520kbyte of on-chip SRAM plus 4Mbyte of on-board QSPI flash. The added wireless interfaces are 2.4GHz 802.11n ...
Arduino announced a single-pair Ethernet adapter board for its Uno R4 single-board microcontroller at Electronica this morning. Microchip participated in the development – its LAN8651B1T-E/LMX single pair Ethernet MAC-PHY – an automotive-qualified part – is used, it said. Single-pair Ethernet is a communication standard that combines data and power on one unshielded twisted pair, for industrial installations over exiting and ...
