Analog Devices has created a pair of 22V stereo Class-D audio amplifier that idle at 6mA and shut-down to microamps. MAX98415A and MAX98425A are similar, and both including envelope tracking control that saves power by instructing an external dc-dc converter to provide the amplifiers main power input with just enough voltage for clean output signals. The difference between the two ...

Analog Devices has created a fast power op-amp that can handle ±55V rails and ±1A outputs, with a digital control bus for setting internal parameters. Called ADHV4710, the output can swing ±52V with ±100mA loading, and its rails can vary down to ±12V. Despite being able to drive ±1300V/μs into 1nF, it is a voltage feedback amplifier, that can handle ...

Cambridge GaN Devices (CGN) has published a video explaining what is different about its novel 650V GaN transistors, which are actually GaN ICs that include circuits as well as the main power switch. The devices do not include a gate driver, but they do include a gate drive modifier circuit which allows any gate driver intended to drive a silicon ...

Artificial intelligence computer vision company Seeing Machines has teamed up with Analog Devices to create an in-vehicle driver fatigue and driver distraction monitoring system. They are aiming at in-cabin DMS and OMS (driver and operator monitoring systems), used in semi-automated vehicle driving systems to improve the chances that the driver is participating appropriately. Seeing Machines is supplying human-monitoring software that ...

Analog Devices has introduced ADIN2299, a multi-protocol industrial 10/100Mbit/s Ethernet switch, designed to operate in a star, line or ring topologies. “The platform was pre-certified so that the field device can operate in any of the supported industrial Ethernet networks,” according to the company. “The module contains everything needed to participate in a EtherCat, Profinet real-time and isochronous real-time, EtherNet/IP ...

The Relays Group of CUI Devices has introduced a line of signal relays for for low-level current switching in industrial, security, test and measurement applications. The will switch up to 2A or 3A in SPDT (1 Form C) or DPDT (2 Form C) form. The gold-silver overlay contacts are rated at 120/125Vac or 24/30Vdc at 1A, and some can switch ...

CUI Devices has announced a collection of IP67 rated waterproof tactile switches. They are: TS03 (left of picture) 6x6mm, 5-9.5mm actuator, 160 – 260g force, through-hole TS05 6×6 mm, 4.3-8mm actuator, 100-260g force, surface-mount TS08 (right of picture) 6x6mm, 4.3mm actuator, 160g force, surface-mount TS19 3x2mm, 0.6mm actuator, 70-240g force, surface-mount All are SPST (single-pole single-throw), and some TS19 versions ...

Analog Devices is to invest €100 million in a Europen research centre in Limerick, over three years. ADI Catalyst will be a 100,000ft2 custom-build its campus on the Raheen Business Park in Limerick. “ADI Catalyst is a state-of-the-art collaboration accelerator where ecosystems of customers, business partners and suppliers engage with ADI,” according to the company. “This latest phase of expansion will ...

Analog Devices has released a Linux operating system based on Raspberry Pi OS for use with Raspberry Pis. Called Kuiper Linux, it incorporates Linux device drivers for ADI products, and supports other hardware including Digilent Zedboard, TerASIC DE10-Nano and Digilent Cora “The reasoning behind creating this distribution is to minimise the barriers to integrating ADI hardware devices into a Linux-based system,” according to the company. “When starting ...

ADA4355 from Analog Devices is a current-input digital-output converter works with pulses down to 10ns for time-of-flight measurements using photo diodes. In a 12 x 6mm BGA package, the IC is actually a hybrid module combining transimpedance amplifier, analogue low-pass filter and 14bit 125Msample/s ADC converter. The output is through two serial LVDS (low-voltage differential signalling) lanes at up to 1Gbit/s/lane. The data clock ...
